Standards:IEC/EN 60898-1 IEC/EN 60947-2 Number of Poles: 2 Tripping Characteristic: B Rated Current (In):63 A Rated Operational Voltage:acc. to IEC 60898-1 400 V AC acc. to IEC 60947-2 440 V AC Power Loss: 9.6 W at Rated Operating Conditions per Pole 4.8 W Rated Insulation Voltage (Ui):acc. to IEC/EN 60664-1 440 V Operational Voltage:Maximum (Incl. Tolerance) 125 V DC Maximum (Incl. Tolerance) 440 V AC Maximum 440 V AC Maximum 125 V DC Minimum 12 V AC Minimum 12 V DC Rated Frequency (f):50 Hz 60 Hz Rated Short-Circuit Capacity (Icn):(400 V AC) 10 kA Rated Ultimate Short-Circuit Breaking Capacity (Icu):(230 V AC) 25 kA (440 V AC) 15 kA Rated Service Short-Circuit Breaking Capacity (Ics):(230 V AC) 18.8 kA Color: WHITE Weight(KG): 0.250
Standards:IEC/EN 60898-1 IEC/EN 60947-2 Number of Poles: 2 Tripping Characteristic: B Rated Current (In):63 A Rated Operational Voltage:acc. to IEC 60898-1 400 V AC acc. to IEC 60947-2 440 V AC Power Loss: 9.6 W at Rated Operating Conditions per Pole 4.8 W Rated Insulation Voltage (Ui):acc. to IEC/EN 60664-1 440 V Operational Voltage:Maximum (Incl. Tolerance) 125 V DC Maximum (Incl. Tolerance) 440 V AC Maximum 440 V AC Maximum 125 V DC Minimum 12 V AC Minimum 12 V DC Rated Frequency (f):50 Hz 60 Hz Rated Short-Circuit Capacity (Icn):(400 V AC) 10 kA Rated Ultimate Short-Circuit Breaking Capacity (Icu):(230 V AC) 25 kA (440 V AC) 15 kA Rated Service Short-Circuit Breaking Capacity (Ics):(230 V AC) 18.8 kA
