Excellent high frequency TIG start ensures no failures on ignition with superior arc characteristics for smooth and stable performance
Easy to Use – set up of welding parameters is simple and intuitive
Robust Design – IP23S designed for both fabrication floor or site applications
Advanced TIG controls for full cycle control to match every application you need, and pulse feature up to 500 Hz for perfect control of heat input
PFC ensures a stable arc, resistant to power fluctuations even while working on long extension cables, up to 100 m (PRO version only).
Optional remote current adjustment from: TIG torch, foot pedal, hand remote control
Color: Yellow
Weight(KG): 9.600
Power Supply (V)
115/230 VAC ± 15%, 1ph, 50/60 Hz
MMA Regulation Field
10 - 200
TIG Regulation Field
10 - 200
Duty Cycle at 40° C MMA
25% 200 A / 28.0 V 60% 129 A / 25.2 V 100% 100 A / 24.0 V
Duty Cycle TIG at 40° C
25% 200 A / 18.0 V 60% 129 A / 15.2 V 100% 100 A / 14.0 V
No-Load Voltage (V)
78V DC
Weldable Electrodes
Rutile - Basic - Cellulosic
TIG Weldable Materials
Steel, Stainless Steel, Copper...
Operation with Gas
Yes, in TIG (ARGON)
Ventilated
Yes
Current Output
DC
Thermostatic and Overvoltage Protection
Yes
Generator
Yes
Welding Processes
MMA - TIG
Dimensions (mm)
403 x 153 x 264 mm
Weight (Kg)
9.6
Protection
IP23S
pfc
Yes
