Mode of operation Maintained
Lamp Maxspid 1W T2 SMT LED Lamp
Rated duration 2 hr and others
Mains supply 230 Volts, 50/60Hz
Power consumption 2VA
Battery Nickel-metal hydride
Charge monitor Green LED Ø5mm
Test facility Micro switch
Safety feature Low volt cut-off preventing battery overdischarge
Fitting construction Electro galvanised steel with epoxy powder coating The adjustable fire-retardant lamp-heads allow flexibility in angle of projection. Lamp heads comes with anti-glare lens
Diffuser Fire retardant moulded acrylic
Mounting Recess
Cable entry Ø20mm K/O hole
Weight 2.9kg (gross)
Compliance SS563 : Part 1 & 2, SS 263 : Part 2
